Lcn 4041 Door Closer With Hold Open Arm

Lcn standard 4041h door closer shipped with hold open arm standard plastic cover and self reaming and tapping screws.

Lcn 4041 door closer with hold open arm.

Catalog page n a unspsc 30171514. Non sized cylinder is adjustable for interior doors to 5 0 and exterior doors to 4 0. Hold open cush n stop arm is a heavy duty parallel arm with a positive stop for high volume traffic or potentially abusive installation conditions. Product description features.

R or l stamped on main arm loosen the hold open nut. All meet ansi a156. Lcn closer mounts hinge side top jamb and parallel arm w pa shoe on either right or left swing doors. It meets ansi bhma a156 4 grade 1 standards and ada reduced opening force requirements.

Lcn 4031 hw pa heavy duty door closer hold open arm with pa bracket. Lcn 4040xp hw pa heavy duty door closer hold open arm with pa bracket. Hcush n stop arm hcush is for the lcn 4040 4040xp series surface closers hold open arm that holds the door in an open position until manually closed. Push door open to engage hold open.

4010 hold open arm part number is 4010 3049. This closer is cul listed and ul listed for self closing doors without hold open and boasts a 30 year limited warranty. 4 grade 1 durability strength and performance standards for door controls. Lcn aluminum hold open arm item 46ty43.

Cast iron forged steel arm heat treated steel pinion all weather fluid power size. My part mfr. For frequently used doors these closers last twice as long as standard door closers. To zoom in use the keyboard to focus on the arrow icon within the product image.

The 4010 hold open arms are handed verify correct hand arm. They can replace yale dorma falcon stanley parker and cal royal models with the same mounting hole pattern. Aluminum hold open arm st. The lcn 4040 series has been designed to be used on metal or timber swinging commercial interior exterior doors and is ideally suited for hospitals educational institutional and other high traffic applications.

Model 4040xp 3049cns al. The lcn 4040 series is a heavy duty non handed surface mounted closer. Powder coat tri mount closer. Hold open solutions for fire rated doors incorporate trusted lcn design elements such as the 4000 series cylinder features broad portfolio with single point multi point and tri volt magnet offerings.

44 increased bearing load capacity strongest pinion ever at 3 4journal diameter widest bearing ever at 5 8 stronger pinion teeth new v shieldseal with 20 longer life. A wide choice of options mounting accessories and ease of installation offer maximum versatility. Opened the door to 5 degrees less than the desired degree of hold open. Closers that meet ul 10c for fire rated doors meet positive pressure fire test standards.

Tighten the nut securely. The 4040xp series is lcn s most durable surface mounted heavy duty closer designed for the most demanding high use and abuse applications. Non sized 1 4 4031 cylinder for exterior doors to 36 914 mm and interior doors to 48 1219.
